Fully Automatic Lamination Machine for PVC Gypsum Ceiling Tiles with ISO9001 Certification and 4-8 Million Square Meters Annual Production Capacity

브랜드 이름:	Greens
모델 번호:	FM01
모크:	1 줄
가격:	US $20000-200000
지불 조건:	신용장, 티/티
공급 능력:	연간 10 줄

자세한 정보

제품 설명

자세한 정보

원래 장소:

헤베이, 중국 (본토)

인증:

ISO CE

제품명:

Pvc 석고 천장 타일을 위한 건설물자 생산 기계 생산 라인

예어:

600*600mm 석고 천장 타일 기계

보증:

1년

전압:

380V

힘:

4KW

전자 제어:

PLC 시스템, Siemens 브랜드

라미네이팅 속도:

3-15m/분

자동등급:

오토매틱

포장 세부 사항:

나무 케이스

공급 능력:

연간 10 줄

강조하다:

ISO9001 Fully Automatic Lamination Machine

4-8 Million Square Meters PVC Gypsum Ceiling Tiles Production Line

Frequency Conversion Synchronous Speed Regulating Gypsum Board Lamination Machine

제품 설명

PVC Gypsum Ceiling Tile Production Line

Advanced automatic production line for applying decorative films to gypsum boards and panel materials with high efficiency and precision.

Product Specifications

Attribute	Value
Warranty	1 Year
Voltage	380V
Power	4kw
Electronic control	PLC system, Siemens Brand
Laminating Speed	3-15m/min
Automatic Grade	Automatic

Technical Parameters

Model	LV-130FM01
Max. laminating width	1300mm
Thickness of sheet	5-30mm
Max. Laminating Speed	15m/min
Speed Regulation	Frequency conversion synchronous speed regulating
Installed power	4kw

PVC Gypsum Ceiling Tile Size

595*595*8.0mm

603*603*8.0mm

600*1200*8.0mm

Product Features

Applies decorative films (PVC, aluminum foil) to gypsum boards and panel materials
Advanced full automatic ceiling production line technology
Highly automated operation reduces labor requirements
Multiple automation levels available
Siemens PLC control system for reliable operation
Annual production capacity: 4-8 million square meters
Compatible materials: Gypsum board, PVC film, aluminum foil, adhesive
Certifications: ISO9001, SGS, CE, ROHS

Our Services

Pre-Sales Service:

Technical consultation and support
Sample testing assistance
Factory visit arrangements

After-Sales Service:

Machine installation training
Operator training
Overseas technical support available

About Our Company

We maintain strict quality control systems and working procedures, earning recognition through professional dedication and excellent service. Our commitment to innovation and quality has established our reputation in domestic and international markets.
